Moving from chan_sip to pjsip

Who am I?

Tom De Moor

@ctl_alt_dieliet

Belgium

Developer

Twitter-app for the Digium phones
LDAP-addressbook for the Digium phones

Find them on http://www.asteriskexchange.com

Examples

Find them at: http://www.controlaltdieliet.be/astricon2015/

chan_sip or res_pjsip?

What is wrong with chan_sip?

Nothing?!
Has been modified alot
Hard to maintain
Slowing down further development

PJSIP?

Why is res_pjsip better?

Better configuration
Multiple aors for same endpoint
NAT is less obscure
No user,peer,friend
Better device and mailbox state
Easier, faster and better development
=> It is the future!

Can I run them together?

Yes!
Different port or ip
patch for websockets

Configuration

Try to forget chan_sip
Not a 1 to 1 relationship

Chan_sip basic config


							[general]

							udpbindaddr=0.0.0.0

							[6001]

							type=friend

							host=dynamic

							disallow=all

							allow=ulaw

							context=internal

							secret=1234

PSJIP basic config


							[simpletrans]

							type=transport

							protocol=udp

							bind=0.0.0.0

							[6001]

							type = endpoint

							transport = simpletrans

							context = internal

							disallow = all

							allow = ulaw

							aors = 6001

							auth = auth6001

							[6001]

							type = aor

							max_contacts = 1
							[auth6001]

							type=auth

							auth_type=userpass

							password=1234

							username=6001

Res_pjsip config types


								Transport "transport"

Endpoint "endpoint"

Authentication "auth"

Address of Record "aor"

Endpoint Identification "identify"

Registration "registration"

								Access Control List "acl"

Phone Provisioning "phoneprov"

System

Domain_alias

outbound-publish

Templates and wizards


								The configurtation style is almost the same as chan_sip.

								the only difference is that you have to define which type you are configuring, like an endpoint or a authentication section

								[name]

Type=

Option=value

								Templates (!)

Wizards

Transport

						Binds res_pjsip to an address and a port.

Multiple bindings are possible

Can't reload during runtime

Transport: minimal config


						[smallest]

						type=transport

						protocol=udp

						bind=0.0.0.0

Transport: more config


						[more_complex]

						type=transport

						protocol=udp,tcp,tls,ws,wss

						bind=0.0.0.0:5061

						local_net=192.0.2.0/2

						external_media_address=20.0.113.1

						external_signaling_address=20.0.113.1

Endpoint


							A device that sends/receives calls

						transport

AOR

auth

Endpoint


							[6001]

							type=endpoint

							context=default

							disallow=all

							allow=ulaw

							transport=simpletrans

							auth=auth6001

							aors=6001

AOR: location


							Multiple AORS for 1 device!

AORS can be overwritten or not

Can be static or dynamic (qualify)

AOR: Static


							[6001]

							type=aor

							contact=sip:6001@192.0.2.1:5060

							contact=sip:6001@192.0.2.2:5060

AOR: Dynamic


							[aor]

							type=aor

							default_expiration=3600

                            maximum_expiration=7200

							minimum_expiration=60

							max_contacts=1

							remove_existing=yes

							qualify_frequency=60

							qualify_timeout=3.0

Auth: Password please


							Options /settings for inboud or outbound registration

Auth: Password please


						[auth6001]

						type=auth
						auth_type=userpass

						password=secret

						username=6001

Registration: Plugging your asterisk into the matrix


						Connecting  your Asterisk to another Asterisk

						Used to be:

						register =>username:password@server/context

Registration: example


						[mytrunk]

						type=registration

						transport=simpletrans

						outbound_auth=mytrunk

						server_uri=sip:sip.example.com

						client_uri=sip:1234567890@sip.example.com

						retry_interval=60

Identify: Can we some some id please


						IP-based authentication

						Matches incoming packets => endpoint

						Looks at on source IP adress
						Optional!

						res_pjsip_endpoint_identifier_user pulls the user from the "From:" SIP header

						The module load order and your configuration will both determine whether you identify by IP or by user (res_pjsip_endpoint_identifier_ip loading after res_pjsip_endpoint_identifier_user)

Identify:example


						[mytrunk]
						type=identify
						endpoint=mytrunk
						match=198.51.100.2

Bringing it all together!

NAT-endpoint


							[transport-udp-nat]

							type=transport

							protocol=udp

							bind=0.0.0.0

							local_net=192.0.2.0/24

							external_media_address=203.0.113.1

							external_signaling_address=203.0.113.1

							[auth6001]

							type=auth

							auth_type=userpass

							password=1234

							username=6001

							[6001]

							type = endpoint

							transport = transport-udp-nat

							context = internal

							disallow = all

							allow = ulaw

							aors = 6001

							auth = auth6001

							direct_media=no

							[6001]
							type = aor

							max_contacts = 2

NAT-TRUNK


							[mytrunk]

							type=registration

							transport=simpletrans

							outbound_auth=mytrunk

							server_uri=sip:sip.example.com

							client_uri=sip:1234567890@sip.example.com

							retry_interval=60

							auth_rejection_permanent = no

							retry_interval = 30

							forbidden_retry_interval = 300

							max_retries = 20

							[mytrunk]
							type=auth

							auth_type=userpass

							password=1234567890

							username=1234567890

							[[mytrunk]

							type=endpoint

							transport=simpletrans

							context=from-external

							disallow=all

							allow=ulaw

							outbound_auth=mytrunk

							aors=mytrunk

							[mytrunk]
							type=identify

							endpoint=mytrunk

							match=203.0.113.1

							[mytrunk]

							type=aor

							contact=sip:203.0.113.1:5060

Wizards!


							[my-itsp]

							type = wizard

							sends_auth = yes

							sends_registrations = yes

							remote_hosts = sip.my-itsp.net

							outbound_auth/username = my_username

							outbound_auth/password = my_password

							endpoint/context = default

							aor/qualify_frequency = 15

The dialplan


						exten => _6XXX,1,Dial(PJSIP/${EXTEN}) (dials first contact)

						exten => _6XXX,1,Dial(${PJSIP_DIAL_CONTACTS(${EXTEN})})

						exten => _9NXXNXXXXXX,1,Dial(PJSIP/${EXTEN:1}@mytrunk)

						exten => _9NXXNXXXXXX,1,Dial(PJSIP/mytrunk/sip:${EXTEN:1}@203.0.113.1:5060)

Those little differences


						same => n,Dial(PJSIP/Agent1,,b(set_header^s^1))

						[set_header]

						exten => s,1,Set(PJSIP_HEADER(add,X-My-DNID2)=${MY_DNID})

						 same => n,Return

						  ${SIPPEER(${peer},status)} for PJSIP?

						DEVICE_STATE(PJSIP/endpoint)

Realtime


							Alembic

Many tables
							ps_aors

ps_auths

ps_contacts

ps_endpoints

ps_domain_aliases

ps_endpoint_id_ips
ps_endpoints

ps_globals

ps_registrations

ps_subscription_persistence

ps_systems

ps_transports

Ok, now you have a basic knowledge about pjsip
But who configures its endpoints in long and large textfiles Most of us store all this data in a database. You can do this with pjsip too. Ofcourse, where we store with chan_sip all data in in table, we need much more tables for pjsip Here they are=> Asterisk now uses alembik, when i say during my prestentation: lambiek, that is wrong. Lambiek is very famous in belgium, as a comic figure and a kind of beer.
Alembic updates your tables automaticly when you upgrade your Asterisk. The database tables did change with asterisk 13.2 That is quite annoying, having tables changing in the smale major version But is was a choise at devcon, i think 2y ago, to abandon the rule that no functionalities were added within a branch.

sorcery.conf


							ps_endpoints => odbc,asterisk

							ps_auths => odbc,asterisk

							ps_aors => odbc,asterisk

							ps_domain_aliases => odbc,asterisk

							ps_endpoint_id_ips => odbc,asterisk

							ps_contacts => odbc,asterisk

extconfig.conf


							ps_endpoints => odbc,asterisk

							ps_auths => odbc,asterisk

							ps_aors => odbc,asterisk

							ps_domain_aliases => odbc,asterisk

							ps_endpoint_id_ips => odbc,asterisk

							ps_contacts => odbc,asterisk

Filling it up with data!


					Good news!
					I've made a script for that!

					Download it from
http://www.controlaltdieliet.be/astricon2015/
